Plano-Convex (PCX) Lenses

Plano-Convex Lenses is best used where one conjugate point (object distance S or image distance S' ) is more than five times the other. This lens shape is near best-form for either focusing collimated light or for collimating a point source.


●Product Origin: China
●Shipping Port: Fuzhou China
●Lead Time: 4 working weeks
●Payment: T/T Payment, Western Union

+86-0591-83275656

contact us
Product introduction

Product description




1.What is Plano-Convex Lenses?

Plano-convex lenses are positive focal length Optical lenses that have one spherical surface and one flat surface,which is

ideal element for light collimation or for focusing applications utilizing monochromatic illumination.

2. What fields are Plano-Convex Lenses widely used?

JX-Optics Plano-Convex lenses are widely used in a wide range of applications including：industries, microscopy, laser

processing, projection system, line detector array illumination, robotics, defense and other market spaces because of the

benefit of focusing light.


Specification

Material：Optical glass, BK7, Fused Silica, CaF2,Germanium etc.

Bevel：<0.25mm X 45°

Demand

Standard

High Precision

Diameter Tolerance

+0/-0.1mm

+0/-0.05mm

Focal Tolerance

±0.1

±0.02

Surface Quality

60-40

20-10

Clear Aperture

>85%

>95%

 Surface Flatness

N=5， △N=0.5

N=3  △N=0.3

Centration

3 min

30 arcset

Coating:

Single layer MgF2;

Multiple layers BBAR coating.
